Legrand MWS5-AD-SA-C push-button panel White

The MWS5 series of miniature microwave presence detectors provide automatic control of lighting loads with optional manual control.

As a standalone product, it is designed to be fitted unobtrusively into ceiling tiles or solid ceilings using the supplied clips. Three models are available: premium, direct dim, and analogue dim all of which will switch incandescent, fluorescent and compact fluorescent lighting.

The direct dim variant controls DALI or DSI digital dimming ballasts whilst the analogue dim variant controls 1-10V dimming ballasts. The unit detects movement using a microwave sensor and turns the load on. When an area is no longer occupied the load will switch off after an adjustable time out period.

Functionality is fully programmable using either the UHS5 or UNLCDHS handsets.

Key features:

Presence detection and switching with lux level sensing

Absence detection functionality

User handset available to control on/off and lux levels

Time delay function

Programmable via our programming handset

Available options:

LV - Low voltage

MWS5 - Key features of 1–10V Analogue Dimming detectors include:

Switching/dimming with lux level lensing

Switching with lux level sensing

Programmable via our programming handset

User handset available to control on/off and lux levels

Step-down illuminance

Maintained illuminance (daylight linking or daylight harvesting)

Suitable for all lighting types

Two channel flexibility

Scene setting and recall

Lamp burn-in

User handset available to control on/off, lux levels and preset scenes
