Legrand EBDHS-AD-LT30 push-button panel White

EBDHS-LT30 is an increased performance PIR presence detector developed for high bay lighting control in areas with demanding spaces and increased mounting heights.

Key Features:

Best in industry detection range – up to 40m at 15m mounting height

Maximum mounting height up to 20m dependent on operating parameters

Operating temperature range -30ºC to 35ºC

IP65 rated

Unique lens technology – high sensitivity within the detection range

Available in Analogue / Digital Dimming and Switching versionsIdeal for cold storage warehousing lighting control

Supplied with adjustable masking shields to tailor detection zones

Verify feature – reduces false triggering by ensuring detection from more than one of the internal

Compatible with the UHS5 or UNLCDHS handsets for easy programming

EBDHS is also available in standard switching/dimming versions.

EBDHS-LT30 - Key features of 1–10V Analogue Dimming detectors include:

Switching/dimming with lux level lensing

Step-down illuminance

Maintained illuminance (daylight linking or daylight harvesting)

Suitable for all lighting types

Scene setting and recall

Lamp burn-in

User handset available to control on/off, lux levels and preset scenes
